Automatic milk filling machine equipment selection guid

Filling machines are indispensable equipment in modern industrial packaging machines and are widely used in food, beverage, medicine, cosmetics and chemical industries. Whether it is liquid, paste or granular materials, filling machines can complete the product packaging in an efficient and accurate manner to meet the production needs of different companies and small entrepreneurs.

 this article will introduce you to the solution of automatic milk filling using filling machines.

I will introduce you to this filling production line that integrates bottle unscrambler, filling machine and capping machine. If you want to use a bottle filling machine to package milk, then I think this machine will definitely meet your various needs.

How does a filling machine work?

There are two ways of filling machines: automatic or semi-automatic. This industrial packaging machine can divide the liquid, paste or other materials to be packaged into containers (such as bottles, bags or cans) to complete the filling task.

The milk filling workflow is as follows:

(1) Bottle unscrambler

The bottle unscrambler will put the bottles waiting to be filled on the conveyor belt and wait for the conveyor belt to start, and send the bottles to the front one by one.

(2) Dispensing plate and filling

Then they enter the dispensing plate position in turn, pass through the dispensing plate gap, and after the bottle stops, the filling head falls into the bottle to fill the sucked milk, filling 2 bottles each time. The dispensing plate moves intermittently, and the turntable sends 2 bottles forward every time it rotates through 2 stations, and then stops entering the dispensing plate gap.

(3) Capping

The bottle caps are arranged in a row by the electromagnetic oscillation hopper, and all the mouths enter the dispensing track with the mouth facing upward. The lower mouth of the capping track is directly opposite to the center of the gap of the dispensing plate. After the bottle enters the gap of the dispensing plate, it rotates with the dispensing plate, so that the bottle mouth of each bottle takes the bottle cap at the lower end of the bottle cap track and puts on the bottle mouth; when the bottle with the cap enters the sealing position with the rotation of the dispensing plate, the sealing seat falls, tightens the bottle cap and the bottle mouth, and the sealed bottle is sent into the dispensing hopper through the rotation of the dispensing plate.

Different types of filling machines have different working principles. For example, automatic volumetric piston filling machines use piston movement to control the filling volume, while liquid filling machines may use gravity, air pressure or vacuum technology.

Features of fully automatic glass bottle raw milk filling and capping machine

 Efficient automation

Automatic operation: This filling machine realizes the automated process from feeding, filling to sealing, which can significantly improve production efficiency.

Fast production speed: Automatic filling machines are particularly suitable for large-scale production lines, with filling speeds of up to dozens to hundreds of containers per minute.

Accurate measurement

High-precision control: Measuring methods such as flow meters, piston pumps or weighing systems are used to ensure that the weight or volume of materials filled each time is consistent.

Reduce waste: Accurate measurement reduces over- or under-filling, saving you production costs.

Strong flexibility

Adapt to different specifications: Supports adjustment of filling volume, filling speed and packaging size to meet the diverse production needs of your production line.

Multifunctional options: Supports a variety of filling heads, heating devices, anti-drip systems or aseptic filling functions.

Hygiene and safety

Food grade materials: Most filling machines are made of stainless steel and meet the standards of the food hygiene and pharmaceutical industries (such as GMP specifications). As a food packaging machine, it is safer and meets food safety to protect your production line.

Common filling machine types

1.Automatic filling machine

Features: Fully automatic operation, from feeding, filling to sealing, integrated, suitable for mass production.

Applicable scenarios: Food and beverages (such as water, juice, milk), medicine (such as oral liquid), cosmetics (such as lotion, essence).

2. Semi-automatic filling machine

Features: Some operations need to be completed manually, such as placing or removing containers.

Applicable scenarios: Small businesses or start-ups.

3. Automatic volumetric piston filling machine

Features: Use the forward and backward movement of the piston to accurately control the filling volume, suitable for high-viscosity materials (such as honey, sauces, lotions).

Applicable scenarios: Food, cosmetics, chemical industries

Advantages: High precision, strong adaptability, suitable for pastes, viscous liquids and granular materials.

4. Automatic milk filling machine

Features: Designed for milk and other liquid beverages, supporting vacuum filling or aseptic filling technology.

Applicable scenarios: Dairy industry, such as milk, yogurt, and milk tea.

Advantages: Ensure uniform liquid flow rate to prevent leakage or contamination.

After the above introduction, it shows that this fully automatic glass bottle raw milk filling and capping machine can quickly realize milk bottle filling. The milk filling machine provides a perfect solution for the food industry and is a major advancement in industrial machinery. Choosing the right packaging and solution can help your company gain more advantages.
